OM11 3000Nm Electric Actuator

OM11 3000Nm Electric Actuator

Quarter-turn Electric Actuator 90 degrees turn OM10 series from Sun Yeh

Specification Overview:

Power: 180W
Max Torque: 2500Nm / 22137 lb.in
Speed: 58 seconds / 90 degree
Weight: 71Kg
Manual Override: Hand wheel
Mounting ISO: F16

IP 67 Nema 4X water proof and dust proof enclosure made of Dry powder coated aluminium alloy

Standard motor is F class with H class option, 35% duty cycle or 75% with optional H class motor

Working conditions: -30C to +65C
Humidity conditions: 40-95%

Manual override: Non clutch design operated.

Thermal motor protection for increase in valve torque to protect the motor.

Options Include: Epoxy coated, modulating controller. speed control, local control, SS housed and many more such as IP68. Call for details.






Technical Datasheet          Available as Actuated Valve




The following sizes are listed below :

OM11 3000Nm Electric Actuator OM11 24V/110V/240V NOT STOCKED, FACTORY LEAD TIME CALL FOR DETAILS
Ref: OM11

Price: CALL

Quantity:





Stock Status Explained !



Stock = Available for Next Day Delivery *

Stock Due 2-3 days = Delivery available within 2-3 days of order. *

Stock Due 7-10 Days = Stock is coming in from Spain or one of of our European/Far East suppliers. Check for firm delivery date to be sure prior to ordering.


Note that we will be making some changes to our website(s) over the coming weeks and months. We are adding new products, brands and more technical information than ever.


We are also making changes so that if you are NOT looking for quantity based products, we can take you to the items we sell as 1 off quantity allowing to buy the quantity you require rather than the box quantity we sell at.


General Note:

Please place your order by selecting the valve size you require above. Quantities shown are per box and quantity discounts relate to the number of boxes ordered. (Please note if the item name (description) above does not show a box qty - the box qty is 1. All items are sold as individual items unless specified as a box qty.
