110/240V SS S.E. 3 Way T Diverting, J+J Electric Actuator, On-Off

2" 3WAY SS BALL VALVE T PORT DIVERT FW J3 ELECTRIC ON/OFF ACTUATOR 110/240V


110/240V SS S.E. 3 Way T Diverting, J+J Electric Actuator, On-Off
List Price: £852.18
Product Code: 2303-09-H-TPD
Stock Status:   In Stock

Buy 3 and save 10% - Price Each: £766.96
Buy 5 and save 20% - Price Each: £681.74
Buy 10 and save 30% - Price Each: £596.53

Quantity :


Please select tab for additional information and purchase options.

  • OVERVIEW
  • SPECIFICATIONS
  • ACCESSORIES
  • DATASHEETS
  • VIDEOS
  • SPARES

actuated valves

Side entry 3 way T port diverting stainless steel ball valve, PTFE seats, ends BSP female, designed for automation, fitted with J+J IP67 on-off electric actuator, supplied fully assembled & dry bench function tested.

Voltage:       110-240V AC/1ph or DC
                       (Multi-voltage capable with automatic voltage sensing)

Flow:             3WTD = Diverts the flow, but with straight through flow in one position

A 3 way T port with diverting flow (3WTD) is popular because in one direction the flow is straight through the valve, dramatically reducing the pressure drop across the 3 way ball valve.  This is a significant advantage over the L port diverting 3 way ball valve.

From the table below you can select the valve size you require and add it to your order, please make your selection based on the intended maximum working temperature of your application:

Working temperature:  Below +70ºC
                                         +70ºC to +120ºC

Specifications for the item are coming soon.
There are no associated accessories for this item.
There are no datasheets available for this item.
There are no videos available for this item.
There are no associated spares for this item.


< Go Back To Product Sizes
